19sa is designed according to IP66 and is built-in with 3 types of selectable analogue output types, i.e. 0-5V, 0-10V, 4-20mA. All these 3 outputs are supported by a 16-bit digital to analogue converter with output accuracy better than 1/65000. Whereas the weighing accuracy is guaranteed by our OIML 10,000e approved circuit.

19sa comes with a completely sealed and extremely heavy duty SUS304 to make with various application environments.

19sa is designed and programmed to provide fast, easy and straightforward operation to meet an extraordinary wide range of industrial applications which require absolute accuracy in both weighing and analogue output for industrial control.

Thanks to the built-in high-speed micro-processor, unsurpassed innovative program, new linearity compensation method, wide range of flexible, selectable operation parameters and selectable AD conversion speed.

Reliability and durability are safeguarded and guaranteed by the carefully selected components from renowned manufacturers as well as smart designed and well-planned circuits.

19sa always deliver more than it is expected and the #1 choice whenever & wherever performance, reliability, durability and flexibility are of no compromise.

Functions

• Static, Dynamic & Animal Weighing, Piece Counting and Peak Hold
• Selectable 0-5V, 0-10V and 4-20mA Analogue Output
• Analogue Output can be Based on Gross or Net Weight Result
• Support Single Range, Dual Range and Dual Interval Operation
• Near Zero Weight Value for Dynamic Weighing to avoid False Signal Output
• User Selectable Analogue Output based on Gross or Net Weight Results
• Add-Tare-Memory (ATM) & Remove-Tare-Memory (RTM) Function
• Manual, Preset, Auto, Repetitive and Continuous Tare Operation
• Continuous Tare with Configurable Delay Time before Tare Action
• Weight and Quantity Check Mode
• Quick Access PLUs for Weight Limits, Quantity Limits and Preset Tare Values
• Direct PLUs for Customer & Product Codes
• Check Result Control for Accumulation, Data Printout & Data Output
• Keypad Lock Function

Operation and Management Features

• Full Numeric Keypad
• Configurable Machine ID, Machine Group and Operator Number to Enhance Ease of Multi-Scales Applications and Management Records
• Customer & Product Code Input through Serial Scanner or Keypad
• Customer & Product Code Support Numbers, Alphabets and Symbols Characters
• Support External [Zero], [Tare] and [Print/M+] Key Input through Scanner
• Tri-Color Check Result Indication
• Configurable Keypad, Check & System Buzzer
• 2 x Independently Configurable Bi-Direction Serial Comports. Selectable TTL Output for Comport 1
• Support Inquiry, Setting and Execution Commands through PC
• All Current Operation Results Output in Data Base Format Increases Ease & Efficiency of Data Management, Processing & Analysis
• Support Ticket Printer and Label Printer (Datecs LP-50 & TSC TDP-225, TDP-247, TDP-345, TTP-225, TTP-247, TTP-345)
• Selectable Portrait / Landscape Ticket Printout Format
• 6 x 45mm Huge Size Bold Type Wide Angle LCD Numeric Digits
• Zero, Gross, Net, Weighing Range, Memory & Battery Level & Recharge Indicators
• Watchdog System to Prevent Damages caused by Load Cell Short-circuit.
• Smart Charging Circuits
• Real Time Clock

Connectivity

• 2 x Configurable Bi-Directional Serial Comports. Maximum Baud Rate = 256000
• 9 x Selectable Fixed plus 1 x User Programmable PC Output Protocols
• Support Bar Code Scanner for Customer & Product Code Entries
• Optional Built-in LAN Module for Ethernet and Internet Communication

Apps for Smart Phones & Devices

Free iOS App (i19) & Android App (a19) are available at App Store and Google Play respectively. These Apps are so powerful that actually they turn your smart devices into a handheld terminal, remote display, remote data input center and controller of your FM product connected.
